The Lincoln Sprinter 180Si represents a remarkable achievement in portable welding technology, delivering exceptional performance and versatility in an incredibly compact package. Weighing less than 20 pounds, this lightweight powerhouse offers a substantial 180-amp output capacity that enables welding with electrodes up to 5/32 inches, including demanding 7018 and 6010 varieties. What truly distinguishes the Sprinter 180Si is its comprehensive multi-process capability, combining superior stick welding performance with advanced TIG functionality including high-frequency starting, pulse mode, and full amptrol compatibility.
Engineered for maximum flexibility across diverse applications, the Sprinter 180Si features dual input voltage capability (120V/230V) that allows seamless connection to any common power supply without manual reconfiguration. The system's intuitive interface simplifies setup with clearly displayed parameters, enabling users to quickly dial in optimal settings for any job. The specialized stick welding modes further enhance versatility, with a crisp arc setting providing superior performance on E6010 and E6011 electrodes, while the soft arc mode ensures dependable E7018 arc starting characteristics.
Despite its compact dimensions, the Sprinter 180Si incorporates advanced features typically found only in larger, more expensive machines. The high-frequency TIG start capability ensures precise arc initiation without tungsten contamination, while the pulsed TIG mode provides enhanced heat management and control for thin, precise welds. The system's exceptional portability is complemented by thoughtful design elements including an ergonomic handle and included shoulder strap, making it ideal for maintenance work, light fabrication, structural applications, and field repairs where mobility is essential. This factory demo unit offers an exceptional opportunity to acquire Lincoln's advanced portable welding technology at enhanced value.
- Dual Input Voltage - 120V and 230V inputs so you can plug into any common power supply.
- Multi-Process Capable - Welds DC Stick and DC TIG.
- Two Stick Modes - Crisp arc allows for greater welding versatility and superior performance on E6010 and E6011 electrodes while soft arc allows for dependable E7018 arc starting.
- Pulsed TIG Mode - Provides heat management and enhanced control when making thin, precise welds.
- High Frequency Start - Strike a precise arc every time while TIG welding
- Lightweight Portability - This durable machine weighs under 20 lbs. and is easy to carry with its ergonomic handle or included shoulder strap.
| Phase 1: Input Voltage #1 (Voltage/Phase/Hertz) | 120/1/60 |
| Phase 1: Rated Output #1A (Current/Voltage/Duty Cycle) | Stick 85A/23.2V/40% |
| Phase 1: Rated Output #1B (Current/Voltage/Duty Cycle) | TIG 110A/14.6V/40% |
| Phase 1: Input Current at Max Rated Ouput #1 (Current) | 22A |
| Phase 1: Input Voltage #2 (Voltage/Phase/Hertz) | 230/1/60 |
| Phase 1: Rated Output #2A (Current/Voltage/Duty Cycle) | Stick 180A/26.4V/25% |
| Phase 1: Rated Output #2B (Current/Voltage/Duty Cycle) | TIG 200A/16.4V/25% |
| Phase 1: Input Current at MAX Rated Output #2 (Current) | 29A |
| Dimensions (H x W x D) | 11.8 in x 6.25 in x 16 in (299.7 mm x 158.8 mm x 406.4 mm) |
| Net Weight | 20 lbs (9.1 kg) |
| Machines Processes | Stick (SMAW) TIG (GTAW) |
| Open Circuit Voltage | Average OCV - 65V Peak OCV - 110V VRD OCV (Peak) - 14V |
| Number of Operators per Machine | 1 |
| Input Voltage | 120/230 |
| Input Hertz | 60 |
| Input Phase | 1 |
| Input Power | 120/230/1/60 |
| Mode Icon | CC |
| Output Range | SMAW 120V: 20-85A 230V: 20-180A GTAW 120V: 10-110A 230V: 00-200A MAX OCV 110V |
| Polarity | DC |
| IEC Rating | IP21S |
| Output Range by Mode | Stick 20A-180A TIG 10A-200A |
| Machines Communication Technology | analog |
| Work Lead Connector Type | Dinse |
| UI type | Simple |
| Typical Application | Construction Brewery Distillery General Fabrication Maintenance & Repair Repair Welding Shipbuilding Structural Welding |
| Warranty | 3 Years |
