Harris  |  SKU: 4000580

Harris 447-50-1/4 in. rh f pipeline single stage air/inert gas regulator - 4000580

$288.99 $384.31
Model 447-50-1/4 in. (RH) (F) heavy duty back-entry single-stage pipeline Air/Inert Gas regulator

Financing / Leasing Available

Welding Equipment And Industrial Supplies Financing

Welding Mart has partnered with Clicklease to provide industry-leading welding equipment for a low monthly payment customized to fit your budget. Our welder financing services allow professionals to outfit their shop with the right welding machines and systems to serve customers. Whether you need a new MIG welder, a rental TIG welder, a virtual welding training simulator or something else, rent-to-own welders from leading brands such as Lincoln Electric and Miller are a great solution.

It's never been easier to afford the equipment you need to grow your business.
Apply in just four minutes and get real approval in seconds - there's no hard credit pull and no documents are needed.

Benefits of Lease-to-Own Welders

A welding machine rental is great for short-term and long-term business needs. Welder leases and rentals let companies stay on top of the latest welding technology without draining their operating budget by paying upfront, in full for new machines. At the end of the lease period, you can either purchase the welding equipment outright or return it to WeldingMart. You can also buy the equipment anytime within the first year of your lease - see below for more details.

Welder rentals can also have tax benefits. In many cases, the payments you make when you lease or finance a welding machine for business or educational purposes are tax-deductible. This frees up even more resources to get the equipment, supplies and personnel that welding businesses need.



More Information

Welding machine financing is available 24/7 so you can apply whenever it's convenient for you. It will only take about four minutes of your time.

Once approved, you'll have the option to select the term that best fits your budget and, if approved for more than you request, our calculator makes it easy to see how your payments change for any additional items you add to your lease. eDocs are available immediately, allowing you to order your new gear within minutes.

Have additional questions? Contact us to speak with a member of the WeldingMart team.

DETAILS

Harris 447-50-1/4 in. (RH) (F) Pipeline Single Stage Air/Inert Gas Regulator - 4000580

Model 447 Regulator is designed to deliver high gas flows from piping systems that are equipped with standard pipe connection outlets. This heavy-duty, high flow, pipeline Air/Inert Gas Regulator has back entry access and a 1/4 in. NPT inlet connection. It features a brass body and bonnet, 2.5 in. dual scale brass gauge, brass T-screw adjustment handle and one-piece encapsulated seat design with internal filter and PTFE Teflon seat.

Features

  • Provides high gas flows for piping systems
  • Designed to work with back-entry standard pipe connection outlets
  • Easy-to-operate brass T-screw adjusting handle
  • Forged brass body and bonnet for longer service life
  • Rubber diaphragm for better pressure control
  • 2.5 in. Brass-plated steel dual scale easy-to-read gauges (psi/kPa)
  • One-piece encapsulated seat design with internal filter to protect the PTFE Teflon seat from particulate contamination
  • 1/4 in. NPT (F) inlet connection
  • 9/16 in. - 18 RH (F) outlet connection

Specifications

Equipment

Adjusting Screw Brass T-screw
Body Forged brass
Bonnet Forged brass
Capacity High flow
Certification CGA E-4
Cv 0.53
Delivery Pressure Gauge (PSIG) 100
Delivery Pressure Range (PSIG) 0 - 50
Diaphragm Rubber
Duty Heavy
Gas / Gas Service Air, Inert gas
Gauges 2.5 in. Brass-plated steel dual scale (psi/kPa)
Inlet Connection 1/4 in. NPT (F)
Maximum Inlet Pressure (PSIG) 500
Outlet Connection 9/16 in. - 18 RH (F)
Pressure Regulation PSIG/100 PSIG 1.6
Recommended Items/Accessories Station drops and valves (Contact Harris Customer Service for assistance)
Seat PTFE Teflon®

Warranty

Warranty 7 Years

Harris 447-50-1/4 in. (RH) (F) Pipeline Single Stage Air/Inert Gas Regulator - 4000580

Model 447 Regulator is designed to deliver high gas flows from piping systems that are equipped with standard pipe connection outlets. This heavy-duty, high flow, pipeline Air/Inert Gas Regulator has back entry access and a 1/4 in. NPT inlet connection. It features a brass body and bonnet, 2.5 in. dual scale brass gauge, brass T-screw adjustment handle and one-piece encapsulated seat design with internal filter and PTFE Teflon seat.

Features

  • Provides high gas flows for piping systems
  • Designed to work with back-entry standard pipe connection outlets
  • Easy-to-operate brass T-screw adjusting handle
  • Forged brass body and bonnet for longer service life
  • Rubber diaphragm for better pressure control
  • 2.5 in. Brass-plated steel dual scale easy-to-read gauges (psi/kPa)
  • One-piece encapsulated seat design with internal filter to protect the PTFE Teflon seat from particulate contamination
  • 1/4 in. NPT (F) inlet connection
  • 9/16 in. - 18 RH (F) outlet connection

Specifications

Equipment

Adjusting Screw Brass T-screw
Body Forged brass
Bonnet Forged brass
Capacity High flow
Certification CGA E-4
Cv 0.53
Delivery Pressure Gauge (PSIG) 100
Delivery Pressure Range (PSIG) 0 - 50
Diaphragm Rubber
Duty Heavy
Gas / Gas Service Air, Inert gas
Gauges 2.5 in. Brass-plated steel dual scale (psi/kPa)
Inlet Connection 1/4 in. NPT (F)
Maximum Inlet Pressure (PSIG) 500
Outlet Connection 9/16 in. - 18 RH (F)
Pressure Regulation PSIG/100 PSIG 1.6
Recommended Items/Accessories Station drops and valves (Contact Harris Customer Service for assistance)
Seat PTFE Teflon®

Warranty

Warranty 7 Years
