Lincoln Cross Country 300 Kubota Engine Driven Welder - K4166-1
The Lincoln Factory Demo Vantage 520 SD Deutz One-Pak Engine Driven Welder Base Model, part number U4107-1, is a high-performance, industrial-grade solution for welding and power generation. Designed for extreme job site environments, this durable engine-driven welder is powered by a robust Deutz® diesel engine, delivering reliable performance and exceptional fuel efficiency. With 520 amps of welding output, the Vantage 520 SD is perfect for heavy-duty Stick, TIG, MIG, Flux-Cored, and arc gouging applications, making it an ideal choice for construction, pipeline, and maintenance projects.
The machine’s advanced features include multi-process capability and auxiliary power generation, providing up to 20,000 watts of clean single-phase or three-phase power for running tools and equipment. Built for rugged reliability, the Vantage 520 SD is designed with an enclosed case to protect components and withstand harsh conditions. Its digital weld meters allow for precise control and monitoring of welding parameters, ensuring optimal performance for any application.
Key Features
- Powerful Welding Output: 520 amps of welding output for Stick, TIG, MIG, Flux-Cored, and arc gouging applications.
- Deutz® Diesel Engine: Reliable and fuel-efficient power for demanding job site conditions.
- Auxiliary Power Generation: Provides up to 20,000 watts of clean single-phase or three-phase AC power for tools and equipment.
- Multi-Process Capable: Supports a wide range of welding processes, from Stick to advanced TIG and MIG.
- Rugged Design: Enclosed case protects components and ensures durability in extreme environments.
- Digital Weld Meters: Precise control and real-time monitoring of welding parameters for superior results.
Specifications
Product Weights & Dimensions
| Dimensions (H x W x D) | 31.9 in x 25.3 in x 56.0 in (810 mm x 643 mm x 1422 mm) |
| Net Weight | 1034 lbs (469 kg) |
Machines
| Machines Processes | Stick (SMAW) Gouging (CAC-A) TIG (GTAW) MIG (GMAW) Flux-Cored Self-Shielded (FCAW-S) Flux-Cored Gas-Shielded (FCAW-G) |
| IEC Rating | 300A / 32V / 100% @ 104°F (40°C) |
| Max Rating | 350A / 28V / 100% @ 104°F (40°C) |
| Output Range by Mode | Stick: 40 – 300 Amps, Touch Start TIG: 20 – 250 Amps, CV-Wire: 14 – 32 Volts |
| Open Circuit Voltage | 80 Peak OCV @ 1800 RPM |
| Rated Gouging Carbon Diameter | 1/4 in (6.5 mm) |
Engine Driven Welders
| Single Phase Auxiliary Output | 10,000 Watts Continuous, 120/240V |
| Three Phase Auxiliary Output | 11,000 Watts Continuous, 240V |
| Auxiliary Output Frequency | 60 Hz |
| Receptacle Types | NEMA 5-20R NEMA 14-50R NEMA 15-50R |
| Engine Brand & Model | Kubota® V1505 |
| Engine Description | 4 Cylinder Naturally Aspirated Water Cooled Diesel Engine |
| Engine Horsepower | 22.0 hp (16.4 kW) |
| Engine Block Size & Displacement | 91.4 cu. in (1.5 L), Bore x Stroke - 3.07 in x 3.09 in (78 mm x 78 mm) |
| Emissions Rating | US EPA Tier 4 Final |
| High Idle Operating Speed @ Rated Output | 1800 |
| Low Idle Operating Speed | 1350 |
| Fuel Tank Size (US gal.) | 11.6 US gal. |
| Fuel Tank Size (L) | 44 L |
| Oil Capacity (qts.) | 6.4 qts. |
| Oil Capacity (L) | 6.0 L |
| Coolant Capacity (US gal.) | 1.2 US gal. |
| Coolant Capacity (L) | 4.5 L |
Application
| Typical Application | Construction Cross Country Pipeline Construction & Field Erection High-strength Pipe Maintenance & Repair Oil & Gas Pipeline & Offshore Piping Power Generation Structural Fabrication |
Warranty
| Warranty | 3 Years Parts and Labor - Engine warranted separately by engine manufacturer |
