What is the AWS classification of the Lincoln ED033516 Lincoln AK-10 Stick (SMAW) Electrode, 5/32x14 in, (4) 5 lb Tube?

The Lincoln ED033516 Lincoln AK-10 Stick (SMAW) Electrode, 5/32x14 in, (4) 5 lb Tube carries AWS E7018 H8 classification. The AWS electrode classification system encodes the electrode's minimum tensile strength (first two digits, in ksi), recommended positions (third digit), and coating/current type (fourth digit). For example, E7018 = 70 ksi tensile minimum, all-position, iron powder low-hydrogen coating, AC or DC+.

What diameter is the Lincoln ED033516 Lincoln AK-10 Stick (SMAW) Electrode, 5/32x14 in, (4) 5 lb Tube available in, and what amperage does each require?

The Lincoln ED033516 Lincoln AK-10 Stick (SMAW) Electrode, 5/32x14 in, (4) 5 lb Tube is available in 5/32 diameter. Electrode diameter selection depends on base metal thickness and joint design: 3/32 in suits 1/16–3/16 in material (40–80A), 1/8 in covers 3/16–3/8 in (80–130A), 5/32 in suits 5/16–1/2 in (110–165A), and 3/16 in+ suits heavy plate over 1/2 in. Always check the electrode manufacturer's current range recommendations for the specific AWS class.

What polarity and current type does the Lincoln ED033516 Lincoln AK-10 Stick (SMAW) Electrode, 5/32x14 in, (4) 5 lb Tube require?

E6010 and E6011 electrodes run on DC+ (direct current, electrode positive) and are designed for cellulosic coatings that generate deep penetrating, fast-freeze arcs — preferred for root passes on pipe and out-of-position work. E6013 runs on AC or DC and is a general-purpose electrode for light fabrication. E7018 is a low-hydrogen iron powder electrode that runs on AC or DC+ — it produces high-quality, low-hydrogen deposits for critical structural and code welding. Never substitute electrode types without understanding the current/polarity requirements.

How should I store low-hydrogen stick electrodes like the Lincoln ED033516 Lincoln AK-10 Stick (SMAW) Electrode, 5/32x14 in, (4) 5 lb Tube?

Low-hydrogen electrodes (E7018, E7016, E8018, etc.) must be stored in a rod oven at 250–300°F after opening to maintain low hydrogen content. Electrodes that have been exposed to moisture for more than 2–4 hours should be re-dried per AWS D1.1 recondition procedures (typically 700–800°F for 1 hour for low-hydrogen electrodes). General-purpose (non-low-hydrogen) electrodes like E6013 are less moisture-sensitive but should still be kept dry. Never use visibly damp or rusted electrodes.

Lincoln ED033516 Lincoln AK-10 Stick (SMAW) Electrode, 5/32x14 in, (4) 5 lb Tube

SKU: ED033516

$134.65 ~~$161.60~~

Lincoln Elite Dealer

Free Shipping over $250

Lowest Price

Mild Steel, Low Hydrogen • AWS E7018 H8

AWS / Classification: E7018 H8

Overview

Lincoln ED033516 Lincoln AK-10 Stick (SMAW) Electrode, 5/32x14 in, (4) 5 lb Tube

Mild steel low hydrogen stick electrode designed for cold re-strike and tacking Retail Small Packaging (RSP). All RSP products carry AWS compliance. Unlike the standard products, RSP products have no other agencies approvals.

Features

• AC polarity welding
• Low open circuit voltage operation
• Minimal spatter
• Capable of cold re-strikes

Specifications

Feature	Value
CONFORMANCES	SPECIFICATIONCLASSIFICATION
AWS	AWS A5.1E7018, E7018-H8
Classification	Yield Strength @ 0.2% Offset, MPa (ksi)Tensile Strength, MPa (ksi)Elongation, %Charpy V-Notch, J (ft-lbs) @ -30°C (-20°F)Hardness Rockwell B
E7018-H8 Requirement	400 (58) min.480 (70) min.22 min.27 (20) min.
Typical Result, As-welded	480-500 (69-72)560-590 (81-86)26-3331-95 (23-70)88-91
Classification	%C%Cr%Mn%Mo%Ni%P%S%Si%V%Mn+Ni+Cr+Mo+VDiffusible Hydrogen, mL/100g Weld Metal1800F H2O - As received
E7018-H8 Requirement	0.15 max.0.20 max.1.60 max.0.30 max.0.30 max.0.035 max.0.035 max.0.75 max.0.08 max.1.75 max.8 max.0.6 max.
Typical Result	0.04-0.060.03-0.040.98-1.320.010.02-0.030.018-0.0190.007-0.0130.33-0.380.021.06-1.403-60.1-0.2
Diameter	PolarityCurrent, Amps
3/32" (2.4 mm)	AC75-120
3/32" (2.4 mm)	DC+70-115
1/8" (3.2 mm)	AC105-150
1/8" (3.2 mm)	DC+100-140
5/32" (4.0 mm)	AC130-200
5/32" (4.0 mm)	DC+120-185
LECO Diameter	5/32 x 14 in (4.0 x 350 mm)
LECO Package	(4) 5 lb Tube
Diameter (in)	5/32
Length (in)	14
