Old Sumner Part Number
780368
Old B&B Part Number
4315
The B&B Sumner High Adjust-A-Roll with stainless steel wheel head, model 4300SSWH, is built for rotating stainless and alloy pipe in sanitary and high-spec process applications at a fixed working height. Stainless steel wheels provide corrosion-resistant, easy-to-clean contact surfaces that help reduce contamination risk, while the 32" (812.8 mm) height offers comfortable access for welding and fit-up.
Key Features
- High Adjust-A-Roll pipe roller with stainless steel wheel head for clean, corrosion-resistant contact.
- Optimized for stainless, alloy, and sanitary piping in process and food-grade facilities.
- Fixed 32" (812.8 mm) working height for consistent weld and inspection positions.
- Stainless wheels support smooth rotation for accurate fit-up and welding.
- Rigid frame provides stable support under heavy pipe loads.
- Compact 32" x 24" x 32" (812.8 x 609.6 x 812.8 mm) footprint for tight work spaces.
- Helps minimize contamination compared to carbon steel contact surfaces.
- Suited for spool shops, chemical plants, and sanitary process installations.
- Engineered for cleanliness, durability, and precise rotation control.
- Load Capacity: 5,290 lbs (2,400 kg) – Height: 32" (812.8 mm)
