Old Sumner Part Number
785280
The B&B Sumner Mini Adjust-A-Roll with steel wheel head, model 4600SWH, is a compact, high-capacity pipe roller stand engineered for pipe rotation and fabrication work in tight or space-limited environments. Despite its small footprint, this mini pipe roller supports loads up to 3,500 lbs (1,588 kg) and handles pipe from 0.5"–36" (12–914 mm), making it ideal for shop benches, portable rigs, and crowded work cells.
Key Features
- Mini Adjust-A-Roll with steel wheel head for general-purpose pipe rolling.
- Compact footprint, approximately 11" x 22" (279 x 559 mm), fits crowded work areas.
- Pipe capacity from 0.5"–36" (12–914 mm) for small bore through medium pipe.
- Steel wheels provide durable, smooth rotation for carbon steel and standard piping.
- Wide, four-legged base helps ensure stability under load.
- Fine adjustment screw and quick-change head allow precise pipe positioning.
- Suitable for floor or bench use in fabrication shops and process plants.
- Ideal for welding, fit-up, inspection, and light coating tasks.
- Engineered for strength, portability, and high performance in tight spaces.
- Load Capacity: 3,500 lbs (1,588 kg) – Pipe Range: 0.5"–36" (12–914 mm)
