Old Sumner Part Number
780361
Old B&B Part Number
4510
The B&B Sumner Table Adjust-A-Roll with stainless steel ball transfer head, model 4500BTH, is designed for multi-directional pipe movement and precise positioning on benches or floors. Stainless steel ball transfers create a low-friction, self-centering support surface that allows pipe to glide and rotate easily during fit-up, alignment, and inspection, especially in high-spec stainless and alloy applications.
Key Features
- Table Adjust-A-Roll with stainless steel ball transfer head for multi-directional pipe movement.
- Rapid, self-centering trestle design for quick pipe placement.
- Adjustable head positions handle pipe from 2"–48" (50.8–1,219.2 mm) OD.
- Stainless ball transfers provide clean, corrosion-resistant contact for sanitary and process piping.
- Excellent for fine alignment and complex fit-up work on tables or floors.
- Reduces operator effort when rotating and shifting heavy pipe sections.
- Compact, low-profile design integrates easily into welding and assembly stations.
- Engineered for control, cleanliness, and efficient pipe handling.
- Ideal for spool fabrication and in-plant process piping projects.
- Load Capacity: 3,200 lbs (1,450 kg)
