Model V-62-5F is a heavy duty 36" straight cutting torch designed to provide maximum performance using low-cost alternate fuel gases.* Harris' special “F” injector can produce the hottest flame possible at the lowest gas pressures (4oz - 2 lbs.) making it the safest, most efficient design in the industry. Model V62-5F features a solid forged brass head, triangular tube design with brazed connections and a solid forged brass cutting lever providing strength, safety and a longer service life. It includes easily replaceable FlashGuard check valves that prevent the reverse flow of gases for added safety. Compatible with Victor style cutting tips. It is UL listed. Torch has a cutting capacity 12" (304.8mm) plate. Alternate fuels include propylene or propane-based fuels and natural gas. NOT FOR USE WITH ACETYLENE.
- Heavy duty UL listed straight hand cutting torch for use with alternate fuels
- "F" injector or low pressure mixing system
- Brazed triangular tube design and brazed connections provide strength and durability
- Solid forged brass head resists abuse and distortion for reliable performance and longer service life
- Flip-up forged brass cutting lever for convenience and ease of operation
- Ease-on cutting valve for safety, smoother starts and more precise cutting control
- Equipped with replaceable FlashGuard check valves
- Cuts up to 12" (304.8mm) plate
- Torch length is 36" (914.4mm)
- Torch head angle is 70◦
| Certification | UL listed |
| Compatible Cutting Tip Model Number - Alternate Fuel (Size) | 1-GPP (000-6) 1-GPP (000-6) |
| Cutting Capacity | Cuts up to 12" (304.8mm) plate |
| Duty | Heavy |
| Equipped With | FlashGuard check valves |
| Gas / Gas Service | Alternate Fuels |
| Head Angle | 70° |
| Mixer Type | F" injector or low pressure |
| Recommended Items/Accessories | Flashback Arrestor Torch Type - Model 88-5-FBT R&L - PN 4302202 |
| Style | V-Series straight hand cutting |
| Torch Length | 36” (914.4mm) |
Warranty
| Warranty | 1 Year |
