Harris 3590-500 Ultra High Flow In-Line Pipleline Regulator - 4000977

$1,005.00 $1,451.33
Model 3590-500 ultra-high flow single-stage pipeline regulator for use with atmospheric or mildly corrosive gases

Financing / Leasing Available

Welding Equipment And Industrial Supplies Financing

Welding Mart has partnered with Clicklease to provide industry-leading welding equipment for a low monthly payment customized to fit your budget. Our welder financing services allow professionals to outfit their shop with the right welding machines and systems to serve customers. Whether you need a new MIG welder, a rental TIG welder, a virtual welding training simulator or something else, rent-to-own welders from leading brands such as Lincoln Electric and Miller are a great solution.

It's never been easier to afford the equipment you need to grow your business.
Apply in just four minutes and get real approval in seconds - there's no hard credit pull and no documents are needed.

Benefits of Lease-to-Own Welders

A welding machine rental is great for short-term and long-term business needs. Welder leases and rentals let companies stay on top of the latest welding technology without draining their operating budget by paying upfront, in full for new machines. At the end of the lease period, you can either purchase the welding equipment outright or return it to WeldingMart. You can also buy the equipment anytime within the first year of your lease - see below for more details.

Welder rentals can also have tax benefits. In many cases, the payments you make when you lease or finance a welding machine for business or educational purposes are tax-deductible. This frees up even more resources to get the equipment, supplies and personnel that welding businesses need.




More Information

Welding machine financing is available 24/7 so you can apply whenever it's convenient for you. It will only take about four minutes of your time.

Once approved, you'll have the option to select the term that best fits your budget and, if approved for more than you request, our calculator makes it easy to see how your payments change for any additional items you add to your lease. eDocs are available immediately, allowing you to order your new gear within minutes.

Have additional questions? Contact us to speak with a member of the WeldingMart team.

DETAILS

Harris 3590-500 Ultra High Flow In-Line Pipleline Regulator - 4000977

Model 3590 is a Single Stage, Stainless Steel diaphragm, Stainless Steel bar stock body Regulator This model also has 2 in. Stainless Steel gauge, a one-piece encapsulated seat design with internal filter and PTFE Teflon seat. Designed specifically for applications demanding extremely high gas flows at low incoming pressures. The Model 3590 features eight functional body ports: two 1/2 in. NPT and six 1/4 in. NPT allowing for a wide variety of inlet/outlet and gauge location configuration. This model is rear-panel mountable. For use with atmospheric or mildly corrosive gases.

Features

  • Provides ultra-high flows for pipeline, manifold and bulk systems
  • Stainless Steel bar stock body and bonnet for longer service life
  • Stainless Steel diaphragm for corrosion resistance and low leakage rate
  • One-piece encapsulated seat design with internal filter to protect the PTFE Teflon seat from particulate contamination
  • Ergonomic ABS plastic knob for easy grip and precise adjustment
  • 2 in. Stainless Steel dual scale easy-to-read gauge (psi/bar)
  • 8 ports: (2) 1/2 in. NPT, (6) 1/4 in. NPT
  • 1/2 in. NPT (F) inlet and outlet connections
  • Rear panel mountable

Specifications

Equipment

Adjusting Knob ABS black plastic
Body Stainless steel barstock
Bonnet Stainless steel barstock
Capacity Ultra high flow
Certification CGA E-4
Cv 1
Delivery Pressure Gauge (PSIG) 1000
Delivery Pressure Range (PSIG) 0 - 500
Diaphragm Stainless steel
Gas / Gas Service Atmospheric or Mildly Corrosive
Gauges 2 in. Stainless steel dual scale (psi/bar)
Inlet Connection 1/2 in. NPT (F)
Maximum Inlet Pressure (PSIG) 500
Mounting Location Rear panel
Outlet Connection 1/2 in. NPT (F)
Pressure Regulation PSIG/100 PSIG 5.5
Recommended Items/Accessories Stainless Steel Bushing - ¼ in. NPT (F) x ½ in. NPT (M) - PN 9005752
Stainless Steel Plug - ¼ in. NPT hex socket - PN 9000553
Seat PTFE Teflon®

Warranty

Warranty 1 Year
