Harris Model HP715-100SCFH-580 240 volt Flowgauge Regulator - 3100223
Model HP715 is an electrically heated Two Stage flowgauge Regulator designed to resist high-flow carbon dioxide (CO2) Regulator freeze-up. It is perfectly suited for gas shielded welding, Ph control, blanketing and purging. The Regulator features chrome-plated brass body, body and 2.5" dual scale gauges, large ergonomic ABS plastic adjusting knob, Stainless Steel diaphragm and one-piece encapsulated seat design with internal filter and PTFE Teflon seat. The heater is 200 watts, 240 volts. The outlet connection is 5/8" - 18" RH (F). Electrical components are UL listed.
Features
- Electrically heated flowgauge Regulator for use with CO2 and Ar/CO2 mixes
- Prevents dry ice from developing in gas systems
- Provides up to 100 SCFH flow at 100% duty cycle
- Thermostatically controlled temperature
- Equipped with a 200 watt, 240 volt electric heater
- Chrome-plated brass body and bonnet for longer service life
- 2.5" chrome-plated brass dual scale easy-to-read gauges
- One-piece encapsulated seat design with internal filter and PTFE Teflon seat to protect from particulate contamination
- Features a Stainless Steel diaphragm to eliminate the absorption and release (or off-gas) contaminants.
3100223
