The Lincoln Cormet SAW Welding Wire is a family of all-positional flux-cored wires for Cr-Mo creep-resisting steel welding in power generation and petrochemical applications. Cormet 1 (CORM1-12N) is formulated for 1¼Cr-½Mo (B2) steels, while Cormet 2 (CORM2-12N) targets 2¼Cr-1Mo (B3) steels. Both deliver high deposition rates, excellent out-of-position operability, and the chemistry required for elevated-temperature service.
- Classification: E81T1-B2 / E91T1-B3
- Alloy class: Cr-Mo
- Polarity: DC+
- Positions: All positions
- Available diameters: 1.2mm
- Process: SAW
- Classification: E81T1-B2 / E91T1-B3
- Cormet 1: AWS A5.29M E81T1-B2C/M-H4 — 1¼Cr-½Mo alloy (B2)
- Cormet 2: AWS A5.29M E91T1-B3C/M-H4 — 2¼Cr-1Mo alloy (B3)
- Process: All-positional gas-shielded flux-cored wire (FCAW-G)
- Shielding gas: 80% Ar / 20% CO₂ or 100% CO₂ (increase voltage 1–2V for CO₂)
- Wire diameter: 1.2 mm
- Current: DC+; Cormet 1: 160–260A at 24–30V
Welding Cr-Mo creep-resisting steels in power generation (boiler pressure parts, steam piping, headers), petrochemical refineries, and chemical processing plants. Cormet 1 for P11/P12 grade (1.25Cr-0.5Mo); Cormet 2 for P22 grade (2.25Cr-1Mo) steels. Both suitable for all-position welding including fixed-position pipe.
- All-positional flux-cored wire — suitable for fixed-position pipe welding
- High purity steel sheath minimizes trace element contamination
- H4 low-hydrogen designation for crack-sensitive high-strength applications
- Cormet 1: up to 550°C (1022°F) service; Cormet 2: up to 600°C (1112°F) service
- High deposition rate vs. SMAW alternatives
- Metal recovery approximately 90% with respect to wire
| Wire | Tensile Strength | Yield Strength | Elongation |
|---|---|---|---|
| Cormet 1 | 635 MPa | 545 MPa | 24% |
| Cormet 2 | 620–680 MPa | 510–560 MPa | 20–26% |
| Diameter | Package |
|---|---|
| 1.2mm | 12 kg |
This Combined Listing parent page aggregates all package sizes and diameters for the Lincoln Cormet SAW Welding Wire product family. Use the variant selector or browse individual child listings to find your specific size and packaging configuration.
