What is the AWS classification of the Lincoln ED023163 Lincolnweld LA-81 Submerged Arc SAW Welding Wire, 5/32 in, 60 lb Coil?

The Lincoln ED023163 Lincolnweld LA-81 Submerged Arc SAW Welding Wire, 5/32 in, 60 lb Coil carries AWS EA2TiB classification. In SAW, the wire/flux combination determines the weld deposit chemistry and mechanical properties — the wire class and flux class are always specified together. Always verify the flux is approved for use with this wire in your Welding Procedure Specification (WPS).

Lincoln Electric Lincolnweld ED023163 Submerged Arc Wire 5/32" – 60 lb

Q: What diameter is the Lincoln ED023163 Lincolnweld LA-81 Submerged Arc SAW Welding Wire, 5/32 in, 60 lb Coil available in?

Common SAW wire diameters range from 5/64 in to 7/32 in. Smaller diameter wire (5/64, 3/32 in) suits lower heat-input applications, tight-groove work, and thinner plate. Larger diameter wire (5/32, 3/16, 7/32 in) maximizes deposition rate for heavy plate and multi-pass structural welds. Consult the wire manufacturer's parameter chart for amperage, voltage, and travel speed by diameter.

Q: What spool or coil size is the Lincoln ED023163 Lincolnweld LA-81 Submerged Arc SAW Welding Wire, 5/32 in, 60 lb Coil available in?

SAW wire is supplied in various coil weights from 25 lb coils to 600 lb reels, depending on the wire diameter and supplier. Heavy production SAW systems use large coils (300–600 lb) to minimize wire change-over time. Ensure your SAW wire feeder head is configured for the specific coil diameter and weight of the product ordered.

Q: How should I store the Lincoln ED023163 Lincolnweld LA-81 Submerged Arc SAW Welding Wire, 5/32 in, 60 lb Coil to maintain weld quality?

Store SAW wire in a clean, dry environment. Surface rust on SAW wire can introduce hydrogen into the weld deposit, increasing the risk of porosity and cold cracking in susceptible base materials. Lightly rusted wire can sometimes be cleaned with a dry cloth, but wire with heavy surface oxidation should be discarded. Keep wire coils sealed in their original packaging until ready for use and store at controlled room temperature with low humidity.

SKU: ED023163

$30,172.51

Financing Options

•

As low as …/mo with.

•

Loading Affirm Estimate…

Lincoln Elite Dealer

Free Shipping

Lowest Price

Low Alloy Solid Electrode

AWS / Classification: EA2TiB

Overview

Lincoln ED023163 Lincolnweld LA-81 Submerged Arc SAW Welding Wire, 5/32 in, 60 lb Coil

Features

A low carbon, medium manganese, high silicon, nickel-bearing electrode designed for use with Lincolnweld® neutral fluxes
Suitable for use in applications requiring less than 1% Ni wire composition
Actual (Type 3.1) certificates for each lot of wire showing chemical composition are available in the certificate center of lincolnelectric.com

Specifications

Feature	Value
LECO Diameter	5/32 in (4.0 mm)
LECO Package	60 lb Coil
Diameter (in)	5/32

Includes

(1) 60 lb Coil

Reviews

Q&A

Product Overview

Lincoln ED023163 Lincolnweld LA-81 Submerged Arc SAW Welding Wire, 5/32 in, 60 lb Coil

Features

A low carbon, medium manganese, high silicon, nickel-bearing electrode designed for use with Lincolnweld® neutral fluxes
Suitable for use in applications requiring less than 1% Ni wire composition
Actual (Type 3.1) certificates for each lot of wire showing chemical composition are available in the certificate center of lincolnelectric.com

Specifications

Feature	Value
LECO Diameter	5/32 in (4.0 mm)
LECO Package	60 lb Coil
Diameter (in)	5/32
