What is the AWS classification of the Lincoln ED023365 Lincolnweld 802 Submerged Arc SAW Flux, 450 lb Drum?

The Lincoln ED023365 Lincolnweld 802 Submerged Arc SAW Flux, 450 lb Drum carries AWS EN 760 – S A CS 1 classification. In SAW, the wire/flux combination determines the weld deposit chemistry and mechanical properties — the wire class and flux class are always specified together. Always verify the flux is approved for use with this wire in your Welding Procedure Specification (WPS).

Lincoln ED023365 Lincolnweld 802 Submerged Arc SAW Flux, 450 lb Drum

Q: What diameter is the Lincoln ED023365 Lincolnweld 802 Submerged Arc SAW Flux, 450 lb Drum available in?

Common SAW wire diameters range from 5/64 in to 7/32 in. Smaller diameter wire (5/64, 3/32 in) suits lower heat-input applications, tight-groove work, and thinner plate. Larger diameter wire (5/32, 3/16, 7/32 in) maximizes deposition rate for heavy plate and multi-pass structural welds. Consult the wire manufacturer's parameter chart for amperage, voltage, and travel speed by diameter.

Q: What spool or coil size is the Lincoln ED023365 Lincolnweld 802 Submerged Arc SAW Flux, 450 lb Drum available in?

SAW wire is supplied in various coil weights from 25 lb coils to 600 lb reels, depending on the wire diameter and supplier. Heavy production SAW systems use large coils (300–600 lb) to minimize wire change-over time. Ensure your SAW wire feeder head is configured for the specific coil diameter and weight of the product ordered.

Q: How should I store the Lincoln ED023365 Lincolnweld 802 Submerged Arc SAW Flux, 450 lb Drum to maintain weld quality?

Store SAW wire in a clean, dry environment. Surface rust on SAW wire can introduce hydrogen into the weld deposit, increasing the risk of porosity and cold cracking in susceptible base materials. Lightly rusted wire can sometimes be cleaned with a dry cloth, but wire with heavy surface oxidation should be discarded. Keep wire coils sealed in their original packaging until ready for use and store at controlled room temperature with low humidity.

SKU: ED023365

$1,401.36 ~~$1,485.00~~

Financing Options

•

As low as …/mo with.

•

Loading Affirm Estimate…

Lincoln Elite Dealer

Free Shipping

Lowest Price

LINCOLNWELD® 802® Submerged Arc flux is ideal for Excellent hot slag removal with wire containing niobium, vanadium or very high chromium levels, typical application on Hardfacing. Use with Lincore® 102W, 423Cr, 423N, 414N, and 102HC (Neutral Flux)

AWS / Classification: EN 760 – S A CS 1; EN 760 – S A CS 2

Overview

Lincoln ED023365 Lincolnweld 802 Submerged Arc SAW Flux, 450 lb Drum

LINCOLNWELD® 802® provides excellent hot slag removal in use with Lincore® 102W, 423Cr, 423N, 414N and 102HC stainless steel wire during welding operations.

Features

Excellent hot slag removal with wire containing niobium, vanadium or very high chromium levels
Lincolnweld 802 Use with Lincore® 102W, Lincore®, Lincore® 423Cr and Lincore® 414N, Lincore® 102HC

Specifications

Feature	Value
LECO Diameter	Flux
LECO Package	450 lb Drum
Diameter (in)	Powder

Includes

(1) 450 lb Drum
