Lincoln Electric Pipeliner ED030924 Flux-Core Wire 5/64" – 14 lb

SKU: ED030924
$547.38 $591.36

Financing Options

•
As low as …/mo with.
•
Loading Affirm Estimate…
Lincoln Elite Dealer
Free Shipping
Lowest Price
Pipeliner® NR-207+ from Lincoln Electric has the portability of stick electrode and the productivity of wire.
AWS / Classification: E71T8-K6, E71T8-A2-K6
Overview

Has the portability of stick electrode and the productivity of wire. It is recommended for hot, fill and cap pass welding of up to X70 grade pipe.

Features
  • Vertical down hot, fill and cap pass welding of up to X70 grade pipe
  • High deposition rates
  • Capable of producing weld deposits with impact toughness exceeding 27 J (20 ft·lbf) at -29°C (-20°F)
  • ProTech® hermetically sealed packaging
  • Q2 Lot® - Certificate showing actual deposit chemistry available online
Specifications
FeatureValue
CONFORMANCES SPECIFICATIONCLASSIFICATION
AWS AWS A5.29E71T8-K6
AWS AWS A5.36E71T8-A2-K6
ABS AWS A5.29E71T8-K6
Classification PolarityYield Strength @ 0.2% Offset, MPa (ksi)Tensile Strength, MPa (ksi)Elongation, %Charpy V-Notch, J (ft-lbs) @ -30°C (-20°F)Charpy V-Notch, J (ft-lbs) @ -40°C (-40°F)Hardness Rockwell B
E71T8-K6 Requirement DC-400 (58) min.480-620 (70-90)20 min.27 (20) min.Info. Only
E71T8-A2-K6 Requirement DC-400 (58) min.480-660 (70-95)22 min.27 (20) min.Info. Only
Typical Result, As-welded DC-440-500 (64-72)550-600 (79-87)25-3291-378 (67-279)31-114 (23-84)87-89
Classification Polarity%Al%B%C%Cr%Cu%Mn%Mo%Ni%P%S%Si%VDiffusible Hydrogen, mL/100g Weld Metal
E71T8-K6 Requirement DC-1.8 max.0.15 max.0.20 max.0.50 - 1.500.15 max.0.40 - 1.000.030 max.0.030 max.0.80 max.0.05 max.
E71T8-A2-K6 Requirement DC-1.8 max.0.15 max.0.20 max.0.50 - 1.500.15 max.0.40 - 1.000.030 max.0.030 max.0.80 max.0.05 max.
Typical Result DC-0.9-1.20.0007 max.0.05-0.080.02-0.050.011.17-1.340.03 max.0.72-0.910.004-0.0100.003 max.0.26-0.310.005 max.5
Diameter PolarityCTWD, mm (in.)⁽¹⁾Wire Feed Speed, m/min (in/min)Voltage, voltsApprox. Current, ampsMelt-off Rate, kg/hr (lb/hr)
5/64 in (2.0 mm) DC-19 (3/4)1.7-3.3 (70-130)18-21210-3052.0-3.7 (4.3-8.1)
Note
⁽¹⁾ For electrical stickout (ESO) subtract 6.4 mm (1/4 in) from contact tip to work distance (CTWD).
LECO Diameter 5/64 in (2.0 mm)
LECO Package (4) 14 lb Coil
Diameter (in) 5/64
Includes
  • (4) 14 lb Coil
