Lincoln Electric SuperArc ED033841 TIG Rod 0.035" – 10 lb

SKU: ED033841
$126.50 $137.80
Lincoln Elite Dealer
Free Shipping over $250
Lowest Price
SuperArc® Orbital TIG L-56 N from Lincoln Electric is a PLW product which has been treated to minimize weld defects that can be seen in the use of MIG wires for the automaticTIG process.
AWS / Classification: ER70S-6
Overview
Lincoln ED033841 SuperArc Orbital L-56 N TIG GTAW Welding Wire, 0.035 in, 10 lb Spool

A PLW product which has been treated to minimize weld defects that can be seen in the use of MIG wires for the automaticTIG process.

Features
  • Q2 Lot® - certificate showing actual deposit composition and actual mechanical properties available online
  • A PLW product which has been treated to minimize weld defects that can be seen in the use of MIG wires for the automatic TIG process

Specifications
FeatureValue
CONFORMANCES SPECIFICATIONCLASSIFICATION
AWS AWS A5.18ER70S-6
Classification Shielding GasPolarityYield Strength @ 0.2% Offset, MPa (ksi)Tensile Strength, MPa (ksi)Elongation, %Charpy V-Notch, J (ft-lbs) @ -30°C (-20°F)
ER70S-6 Requirement 100% ArDC-400 (58) min.480 (70) min.22 min.27 (20) min.
Typical Result, As-welded 100% ArDC-520 (75)620 (90)32325-385 (240-284)
Classification %C%Cr%Mn%Mo%Ni%P%S%Si%V%Total Cu
ER70S-6 Requirement 0.06 - 0.150.15 max.1.40 - 1.850.15 max.0.15 max.0.025 max.0.035 max.0.80 - 1.150.03 max.0.50 max.
Typical Result 0.090.021.450.00 max.0.010.0040.0100.830.00 max.0.16
LECO Diameter 0.035 in (0.9 mm)
LECO Package 10 lb Spool
Diameter (in) 0.035
