Lincoln Tech Rod 276 in 3/32 in x 12 in, packaged as a 8 lb easy-open can for the applications described on the Lincoln Tech Rod 276 family page. Same AWS A5.11/A5.11M ENiCrMo-4 classification as every other size in this product line, packaged in this format for shop and field crews running this diameter.
| Manufacturer SKU | EL190093632 |
|---|---|
| Diameter | 3/32 in |
| Length | 12 in |
| Package | 8 lb easy-open can |
| Net weight | 8 lb |
| Approx. rods per package | ~68 rods |
| Recommended amperage (this diameter) | 50-80 A |
| AWS classification | AWS A5.11/A5.11M ENiCrMo-4 |
ENiCrMo-4 is an AWS A5.11 nickel-chromium-molybdenum SMAW electrode (~57 Ni / 15.5 Cr / 16 Mo / 4 W / UNS W80276) with 100 ksi minimum tensile, designed for welding Hastelloy C-276 (UNS N10276) and similar wet-corrosion nickel alloys used in oxidizing and reducing-acid service, including hot hydrochloric acid, wet chlorine, and FGD (flue gas desulfurization) systems. DC+ in all positions; interpass temperature ≤250 deg F to avoid intermetallic precipitation.
Is this the same electrode as the parent Lincoln Tech Rod 276 grade, just in a different package?
Yes. SKU EL190093632 is the same AWS A5.11/A5.11M ENiCrMo-4 classification as every other size in the Lincoln Tech Rod 276 family. The only difference is diameter (3/32 in) and package format (8 lb easy-open can). Polarity, position, and tensile properties are identical to the parent grade.
How many rods are in this 8 lb easy-open can?
Approximately ~68 rods. Exact count varies with manufacturing tolerance but a 8 lb easy-open can of 3/32 in Lincoln Tech Rod 276 typically contains in this range.
What is the shelf life if I do not use them all?
Sealed containers have an indefinite shelf life when stored in a dry environment. Follow the manufacturer storage instructions on the parent grade page for opened-container handling.
What diameter should I use for common applications?
3/32 in is well-suited for root passes, thin material, and out-of-position work. Heavier base metal and higher deposition typically calls for one diameter up; thinner sheet and root passes go one diameter down. See the parent grade page for full diameter-to-amperage guidance.
Can I mix this size with other diameters on the same job?
Yes, provided your procedure qualification (WPS) covers the diameter range. Many shops use one diameter for root, one for fill, and one for cap. All sizes within Lincoln Tech Rod 276 share identical mechanical properties (AWS A5.11/A5.11M ENiCrMo-4) so weld metal chemistry is consistent across passes.
Do I need to rebake these after the can is opened?
Refer to the parent grade page and manufacturer data sheet for rebake requirements specific to this electrode classification.
Does this size require a special holder or stinger?
Use an electrode holder rated for the amperage range above (50-80 A). Most general-purpose stinger holders (e.g. 300-500 A class) handle 3/32 in Lincoln Tech Rod 276 without issue. For sustained high-amperage runs on larger diameters, a 500 A or higher holder is recommended.
Is this Buy America compliant?
This specific SKU is not the Buy America variant. Lincoln Tech Rod 276 may be available in a Buy America compliant version - see the parent grade page for all available compliance variants.
