Lincoln Electric MIG Wire 0.045" – 250 lb

SKU: MG625045684
$9,441.00 $10,457.50

Financing Options

•
Loading Affirm Estimate…
•
Lease-To-Own From $429/mo — 24-Mo Term, No Hard Credit Check
Lincoln Elite Dealer
Free Shipping
Lowest Price
TECHALLOY® 625 Metal Inert Gas Wire designed for MIG, TIG and SAW welding of nickel-chromium-molybdenum cladding alloys. This filler metal may be used for cladding and welding dissimilar base metals such as Ni-Cr-Mo alloys to stainless and carbon steels.
AWS / Classification: AWS ERNiCrMo-3
Overview

TECHALLOY® 625 0.045 inch welding wire is designed to match the composition and properties of alloy 625. The Ni-Cr-Mo alloy system provides excellent resistance to oxidizing and reducing environments, with the high molybdenum content providing good stress, pitting and crevice corrosion resistance.

Features
  • Designed to match the composition and properties of Alloy 626
  • The Ni-Cr-Mo alloy system provides excellent resistance to oxidizing and reducing environments
  • The high molybdenum content provides good stress, pitting and crevice corrosion resistance
  • Most popular nickel alloy for cladding
  • Provides high temperature strength and structural stability
  • Q2 Lot® - Certificate showing actual wire composition available online
Specifications
FeatureValue
CONFORMANCES SPECIFICATIONCLASSIFICATION
AWS AWS A5.14ERNiCrMo-3
CWB AWS A5.14ERNiCrMo-3
MIL MIL-E-21562EEN625
Classification %Al%C%Cr%Cu%Fe%Mn%Mo%P%S%Si%Ti%Nb+Ta%Ni+Co
ERNiCrMo-3 Requirement 0.40 max.0.10 max.20.0 - 23.00.50 max.5.0 max.0.50 max.8.0 - 10.00.02 max.0.015 max.0.50 max.0.40 max.3.15 - 4.1558.0 min.
Typical Result 0.100.0122.20.010.30.018.80.003 max.0.003 max.0.060.213.4764.8
Diameter Shielding GasPolarityVoltage, voltsApprox. Current, amps
.035" (0.9 mm) 75% Ar, 25% HeDC+26-29160-190
.045" (1.1 mm) 75% Ar, 25% HeDC+28-32180-220
1/16" (1.6 mm) 75% Ar, 25% HeDC+29-33200-250
LECO Diameter 0.045 in (1.1 mm)
LECO Package 250 lb Accu-Trak® Drum
Diameter (in) 0.045
Includes
  • (1) 250 lb Accu-Trak® Drum
