Lincoln Pipeliner Shield-Arc 70+ is an AWS A5.5/A5.5M E7010-G SMAW stick electrode family with 70 ksi minimum tensile and DC+ only, all positions operation. WeldingMart stocks 2 package and diameter variants of this grade, all sharing the same AWS classification - select the diameter and package format that fits your application below.
About Lincoln Pipeliner Shield-Arc 70+
E7010-G is an AWS A5.5 low-alloy cellulosic-coated DC+ SMAW electrode with 70 ksi minimum tensile and a general-classification (G) chemistry agreed between supplier and purchaser. The cellulose coating delivers the deep-penetration, fast-freeze characteristics needed for cross-country pipeline root and fill passes, with low-alloy chemistry tailored to API 5L X-grade pipe applications. DC+ only, all positions.
Specifications
| AWS classification | AWS A5.5/A5.5M E7010-G |
|---|---|
| Minimum tensile | 70 ksi minimum |
| Polarity / position | DC+ only, all positions |
| Available diameters | 3/32 in through 1/4 in (varies by package) |
| Package formats | see size variants below |
Why buy Lincoln Pipeliner Shield-Arc 70+ from WeldingMart
- Brand-authorized distributor - factory-fresh stock, full warranty pass-through
- Multiple diameter and package variants in stock - select the SKU below that matches your job
- US warehouse fulfillment, 1 business day ship time
- 30-day returns on unopened cartons
